Goodman 3 Ton R32 Air Conditioner & 96% 100000 BTU Upflow Gas Furnace

FREE SHIPPING - Great Pricing
Backed by the most knowledgeable staff in the business:
We know HVAC so you don't have to.

ONE OF THE BIGGEST NAMES IN HVAC...
FREE ACESSORIES + FREE SHIPPING!

Goodman is manufactured in Texas and owned by Daikin, one of the most popular choices in home HVAC units. This central air system takes care of heating and cooling your home by combining a highly rated air conditioning condenser, gas furnace, and evaporator coil for the perfect home comfort package.

Goodman Air Conditioning & Gas Furnace Heating System for Northern States
Due to new efficiency requirements, this system cannot be installed in the following states: Alabama, Arizona, Arkansas, California, Delaware, Florida, Georgia, Kentucky, Louisiana, Maryland, Mississippi, Nevada, New Mexico, North Carolina, Oklahoma, South Carolina, Tennessee, Texas, and Virginia.

One easy order with everything needed for install:

• Air Conditioner, Coil, and Gas Furnace System
• 30' Insulated Line Set
• Condenser Wire Whip
• Condenser Pad
• 60 amp Disconnect
• 1H/1C Thermostat

Bundle Model Numbers:

GLXS3BN3610 / GR9S961005CN / CAPTA3626C3 / LS38783830 / 84134 / 83335 / B1020NC / EL3030-3

System Overview

Goodman Upflow 3 Ton 13.8 SEER2 AC & 100,000 BTU 96% AFUE Gas Furnace Split System

SEER Notice: The system SEER can be different from the condenser SEER, the true SEER rating achieved depends on the system as a whole and not just the condenser. We advertise the true SEER of the system and this can be verified with the AHRI number provided in the specs.

The Goodman GLXS3B AC condenser (outdoor unit), GR9S96 gas furnace, and CAPTA coil (indoor units) work together as a mixed electric and natural gas system to provide cooling & heating for your home at an inexpensive price. With a straightforward installation process, you can expect a convenient and hassle-free air conditioning solution, making this system an ideal choice for those seeking a standard efficiency AC and high efficiency furnace system in Northern US States.

System Warranty
GLXS3BN series condensers, GR9S96 series gas furnaces, and CAPTA series coils come backed by Goodman's standard 10 year parts warranty with online registration through the manufacturer within 60 days of installation. Once registered, the furnace also receives an additional lifetime warranty on the heat exchanger and a 10 year limited unit replacement warranty. An installation that follows your state and local codes is required for the warranty to be upheld.

AC Portion Quick Facts

• Ideal size to cover up to a medium size house in ideal climates
• 3 ton, 13.8 SEER2 electric ac system
• R32 - Complies with Clean Air Act regulations
• Condenser is fully pre-charged for up to 15' of line set
• Factory-installed filter drier and extended life capacitors
• Vertical evaporator "A" coil with built-in TXV

3 Ton, 13.8 SEER2
The Goodman GLXS3BN3610 air conditioning condenser unit has a capacity of 3 tons (36,000 BTU) and in an ideal climate, this tonnage will normally cover a medium sized house. The higher the SEER2 rating, the less electricity is needed to keep your house cool in the summer. The condenser by itself is rated for 13.4 SEER2, but when paired with the included coil and furnace, this system achieves a higher efficiency at 13.8 SEER2 -- this means you save more money on electric bills vs a basic system matchup.

In some bundles, the coil associated with the condenser may be intentionally larger in tonnage to maintain the unit's overall efficiency. Efficiency ratings depend on how the system as a whole operates, and not just the condenser - all advertised ratings can be confirmed with the AHRI certificate in this listing.

Heating Portion Quick Facts

• 100,000 BTU, 96% AFUE natural gas furnace
• Upflow orientation when paired with the included coil
• R32-ready without any extra accessories
• Requires plastic/PVC flue pipe for venting
• Single-stage gas valve with 9-speed ECM blower motor
• Can be converted to an LP furnace with a conversion kit (uses model LPM-33, sold separately)

100,000 BTU, 96% AFUE
The Goodman GR9S961005CN gas furnace has an input capacity of 100,000 BTU, while the output of this furnace is 96,100 BTU (100,000 X 96% AFUE) per hour. The higher the AFUE rating, the less gas is lost as exhaust during normal heating operations. 96% efficiency means that 96% of the gas going into the furnace is used to heat your home and the remaining 4% is lost out of the plastic or PVC flue venting.

Please note that this furnace does not comply with California Ultra-Low NOx regulations. If you need help with a quote on a California-friendly system, please contact us through eBay's messaging system.

Unit Specifications

GLXS3B AC-Only Condenser
Goodman GLXS3B series of air conditioning condensers are manufactured with a sturdy, galvanized-steel cabinet that features a baked-on powder-paint finish with easily accessible gauge ports and service valves with sweat connections. The outer casing has both a top and a side access to allow for a faster installation and easier access for maintenance or warranty work when necessary.

Made with high-quality components and enhanced sound-dampening features, the GLXS3B AC unit has some of the lowest sound outputs on a single stage unit in the industry. Moreover, the unit is equipped from the factory with enhanced copper tubing,  aluminum fin coils, and a built-in filter dryer that lowers general wear-and-tear on the unit. All of these features are packed into a highly durable unit designed to lower your installation and maintenance costs, while providing superior comfort you can rely on.

GR9S96 Natural Gas Furnace
The Goodman GR9S96 series of gas furnaces are built with heavy-gauge steel cabinets to protect its internal mechanisms while providing an air-tight barrier that prevents both heat loss and most noise from exiting the unit. Each component of the furnace feature innovative designs including a heavy-duty aluminized-steel tubular heat exchanger, stainless-steel secondary heat exchanger, durable silicon nitride ignitor, self-diagnostic control board, and an energy efficient 9-speed ECM blower motor.

The GR9S96 on its own can be used for upflow or horizontal (left or right) installations; with the included evaporator coil, it will be configured as an upflow system. With single stage operation, this furnace only has one heat output where the burner will either be on at full blast, or shut off completely - nothing in-between. Goodman gas furnaces ship ready to run on natural gas but they can be converted to propane by using the corresponding LP conversion kit, available at an additional cost that consists of a replacement set of orifices and springs.

CAPTA Vertical Evaporator Coil
The Goodman CAPTA features a galvanized, leather grain embossed finish on the outside and foil-faced insulation on the inside to reduce cabinet condensation. Its thermoplastic drain pan resists both rust and UV, with a design that lowers water retention to help prohibit mold growth and keep the air you breathe clean. Moreover, these coils are optimized for use with R-32 including factory installed circuits, manifolds, and a refrigerant sensor designed for the lifespan of the unit.

For easier installation, the CAPTA comes equipped with drain pan rails to easily remove and reposition the coil as needed, and a single front access panel that makes maintenance a breeze. To maintain a higher efficiency, each coil comes with a built-in TXV from the factory and the internal coil (tubing and fins) are all-aluminum for better heat transfer with standard copper stub connections.

Goodman AC & Gas Furnace Split System Specs ' R32 SKU GLXS3BN3610 / GR9S961005CN / CAPTA3626C3 Refrigerant Charge 15' of Line Set Total Weight 331.000000 AHRI Certificate 215277429 AC Cooling BTU / Tonnage 36,000 BTU / 3 Ton Furnace Heating Input / Output BTU Input: 100,000 BTU
Output: 96,100 BTU Operational Stages AC Condenser: Single Stage
Gas Furnace: Single Stage System SEER2
(Whole Season Cooling Efficiency)
13.8
System EER2
(Cooling Efficiency at 95°F Only)
11.2 AC Compressor Type Scroll Liquid x Suction Line Connections
Coil (Indoor): 3/8" x 7/8"
Condenser (Outdoor): 3/8" x 7/8"
Orientation Upflow Electrical Information Condenser: 208/230V 1 Phase 60 Hz
Furnace: 115 V. 1 Phase 60 Hz Min / Max Breaker Size
Condenser: 17.5 / 30 amps
Furnace: 25 amps Furnace AFUE
(Annual Fuel Utilization Efficiency)
96% Furnace Exhaust Flue Requirement Plastic / PVC Furnace NG to LP Conversion Kit
(Must purchase separately when converting furnace for propane operation)
LPM-33 Furnace Blower Motor
9-Speed ECM Furnace Maximum CFM 2161 Mobile Home Approved No Condenser Dimensions
Height: 32 1/2"
Width: 26"
Depth: 26"
Furnace Dimensions
Height: 34 1/2"
Width: 21"
Depth: 28 3/4"
Coil Dimensions
Height: 26"
Width: 21"
Depth: 21"
Warranty 10 Year Parts / 10 Year Replacement on Furnace / Lifetime Heat Exchanger with Online Registration

ACCESSORIES OVERVIEW

30ft Tech Recommended Installation Kit 1H/1C Thermostat
B1020NC
Bright Blue Backlit Screen
Hardwire or Battery Powered
Adjustable Temperature Limits Insulated Line Set
LS38783830
30 Foot Length
3/8" Liquid Line x 7/8" Suction Line
(Packages Include Reducer Fittings as Needed)
Condenser Pad
EL3030-3
30" x 30" x 3" Lightweight, Rugged Pad
High Recycled Plastic Content
UV Resistant / Drillable / Textured Disconnect Switch
83335
Non-Fused / Rated up to 60 Amps
Knockout Dimensions: 1/2" x 3/4" x 1"
Electrical Wire Whip
84134
8 Gauge 3/4" x 4 Foot Length
2 Non-Metallic Liquid-Tight Connectors
3 Conductors (Black, Red, and Green)
